Fixtures and jigs are essential manufacturing aids that ensure precision, repeatability, and safety in CNC machining operations. While often used together, they serve distinct functions in the manufacturing process.
Fixtures securely hold, support, and position workpieces during machining operations. They provide stability and accurate location without guiding the cutting tool.
Jigs not only hold the workpiece but also guide the cutting tool during operations like drilling, tapping, or milling, ensuring consistent results across multiple parts.
Nesting is a technique for optimizing material usage by efficiently arranging multiple parts or contours on a sheet of material to minimize waste.
Designed for CNC turning operations, these fixtures secure cylindrical workpieces and provide rotational stability during machining processes.
Specialized for milling operations, these fixtures hold workpieces securely while allowing access for cutting tools from multiple angles.
Precision fixtures designed for grinding operations that require exceptional accuracy and surface finish quality.
Advanced fixtures with built-in indexing mechanisms for machining multiple surfaces or features with precise angular positioning.
Simple, accurate jigs that provide templates for drilling operations, known for their precision and ease of use.
Specialized jigs for drilling holes at specific angles, essential for complex geometric requirements.
Versatile jigs with built-in clamping systems, suitable for various drilling and machining operations.
Comprehensive jigs that enclose workpieces, enabling multi-directional machining in a single setup.
Engine components, transmission parts, chassis assembly fixtures, and quality control jigs for mass production.
Precision fixtures for aircraft components, turbine parts, and critical safety components requiring extreme accuracy.
PCB assembly fixtures, connector jigs, and precision holding devices for electronic component manufacturing.
Biocompatible fixtures for surgical instruments, implants, and diagnostic equipment manufacturing.
Fixtures for turbine components, solar panel frames, and renewable energy equipment manufacturing.
Custom workholding solutions for diverse manufacturing processes across multiple industrial sectors.
Ensure perfect alignment for maximum accuracy while avoiding over-constraint that could introduce distortion.
Design for one-handed operation to improve efficiency and reduce operator fatigue during production.
Create self-locating and self-clamping mechanisms that minimize human intervention requirements.
Minimize complexity to reduce cycle times and eliminate potential failure points in the system.
Incorporate visual and tactile indicators to immediately identify setup errors or misalignments.
HRC 58-62 for extreme durability and wear resistance
316L grade for corrosion resistance and cleanroom applications
7075-T6 for lightweight yet strong applications
PEEK, POM, and nylon for specialized applications
5-axis precision machining for complex geometries
Rapid prototyping and complex internal structures
Ultra-precise cutting for hardened materials
Optimized hardness and stress relief
Coordinate measuring machine verification
Ra 0.8μm or better surface finish
ISO 9001:2015 quality management
Complete performance validation
Extensive expertise in designing and manufacturing custom fixtures and jigs for global clients across diverse industries.
State-of-the-art 5-axis CNC machines, wire EDM, and precision grinding equipment for exceptional accuracy and surface finish.
Skilled engineers with deep understanding of workholding principles, material science, and manufacturing optimization.
Fast prototyping and production capabilities with typical lead times of 7-15 days for standard complexity projects.
Comprehensive quality control with detailed inspection reports and performance validation for every fixture and jig.
